IP · Sole Systems
Injection-moulded consistency at volume.
Phylon soles, injected rather than compression moulded (IP, also IMEVA), for programmes where the thousandth pair must measure like the first: tight dimensional tolerance, dedicated tooling, repeatable output.
What it is
Injection moulding trades the long cure of compression for a closed, metered cycle: material is injected into the tool, expanded and cooled to a finished dimension with almost no operator variance. Once the process window is set, it holds, which is the whole point at volume.
Dedicated IP tooling is designed and cut in-house, so tolerance corrections are a tooling decision made on our floor, not a supplier negotiation.
Specification envelope
Where a row is marked held in production it is our own window, measured on the compounds we run. The rest describes the family. Values for your specific compound and construction come with the full spec sheet; request it below.
| Material | Injection phylon (IP), also written IMEVA; injection-moulded EVA sole stock |
|---|---|
| Tolerance | Tightest dimensional repeatability of the six families |
| Colour | Uniform through-body colour, run to run |
| Tooling | Dedicated IP moulds, designed and cut in-house |
Tested against
The standards buyers most often write into the specification for this family. In-house rigs run on site; items marked external are booked with an accredited laboratory. Full rig-to-standard mapping is on the quality page.
Where this sole is specified
| Segment | What drives the spec | Tests that gate it |
|---|---|---|
| Casual & Lifestyle | Weight, colour fidelity and unit cost at seasonal volumes | Colour hold · shrinkage & yellowing · abrasion |
| School & Children's | Light, latex-free, softer compounds for younger age groups | Hardness SATRA TM205 · chemical compliance (REACH SVHC, Prop 65) |
Hardness and density
We quote hardness for this construction per programme rather than publishing a window. The figure our own parameter review returned for it was not recorded against a durometer scale, and a hardness stated without saying whether it is Shore A or Shore C is not a specification; it is a number that will be read the wrong way in a purchase order. Send the shoe and the target and we will come back with a figure we can hold, scale included.
Dedicated IP moulds, designed and cut in-house. The tooling investment is the highest entry cost of the six families and the cycle the shortest, which is why IP suits programmes measured in tens of thousands of pairs rather than thousands, and why a tolerance correction here is a decision made on our floor rather than a negotiation with a mould supplier.
How this sole fails, and what sees it coming
Every construction has characteristic failures. A supplier who names them is more use than one who implies there are none, and each of these is caught by a rig on the quality page rather than by an apology afterwards. Acceptance limits are yours to set; what follows is what to look for and when it is cheapest to look.
An injected part leaves the tool and then moves, so the mould is cut oversize by a known allowance per material. Get the allowance wrong and the fault does not appear as one bad sole; it appears across a size run as grading that will not match the last. This is why the first article is measured, not just looked at.
Where the section changes abruptly the surface pulls in as the material cools, and on a sole that reads as a dent in a visible sidewall. It is designed out at DFM review by evening out wall thickness, because at that point it costs a drawing revision rather than a tool.
Material enters at a gate and flows around obstructions, and both leave a mark. They cannot be eliminated, only placed. Agreeing where they are allowed to fall before the tool is cut is the difference between a cosmetic note and a rejected batch on a fashion programme.
When to specify something else
Our own figures, not a category benchmark. Held across the six sole systems; a programme that moves them says so in the quotation. Full terms, tooling cost and mould ownership are on the OEM & ODM page.
The other five systems
Compression-moulded rubber outsoles built for abrasion resistance and grip. Custom tread geometry from your drawing or sample.
Foamed rubber that keeps the wear characteristics of solid rubber while cutting unit weight for all-day comfort.
Thermoplastic rubber soles with fast tooling turnaround and clean colour reproduction. Regrind-friendly process.
Rubber outsole bonded to an EVA midsole: abrasion where the ground is, cushioning where the foot is. Two densities, one part.
The combination sole moulded as a single unit. No bond line to delaminate, fewer assembly steps downstream.
Weighing one material against another? EVA, rubber and TPR compared runs the properties side by side.
Questions buyers ask about this
What is IP injection, and how does it differ from a compression-moulded EVA sole?
IP is injection phylon: EVA sole stock injected into a closed tool rather than compression moulded. Material is metered, injected, expanded and cooled to a finished dimension in one closed cycle, so operator variance is almost removed. Compression moulding is more forgiving on tooling cost; injection is more repeatable once the process window is set.
At what volume does IP injection make sense?
Tens of thousands of pairs rather than thousands. The tooling investment is the highest entry cost of our six families and the cycle the shortest, so the economics turn on volume. Below that, TPR carries a lighter tooling entry cost at comparable cycle speed.
Can an IP injection sole be used as a bare outsole?
It can, for pavement-going casual and school footwear, which is where most IP programmes sit. Where the sole meets genuinely abrasive ground, EVA sole stock is a poor wear surface on its own and a rubber outsole, or rubber over an EVA midsole, is the right specification.
Need the ip injection soles spec sheet?
Send the drawing, the sample or just the shoe it has to survive. We come back with compound, hardness range, MOQ and timing for your programme.
